PlugIn Relay contact for 120V, white background

PlugIn Relay Contact

For 1203X

The DEFA relay contact is designed for the DEFA PlugIn system.

Art. nr: 463432
See specifications
Shortcuts:

Description

The DEFA relay contact is designed for the DEFA PlugIn system. It is the interface to connect a DEFA Control/ Programmable unit; if you are not using the DEFA 1203X on-board charger (this has a built-in relay), but you still want to control/program your cabin or engine heater.

A Y-connector is required any time you need to split the 120V power so that 2 DEFA components can be operated simultaneously.

Technical description

DEFA AS conforms to the requirements of both ISO 9001- 2008, ISO 14001:2004 and OHSAS 18001:2007. In addition, our engine heaters and cables conform to the requirements of ISO/TS 16949:2002.

Dimension
Voltage
Current
Weight
IP rating
HWD: 90/33/67mm - 3.5/1.3/2.6in
120V
15A (max)
59g/2.1oz
IP44

Downloads

Installation instructions (pdf)
Product sheet (pdf)
